Epson TM-T82II-i

Home -› POS-Hardware -› Printers -› Epson TM-T82II-i

Improve Speed / Eliminate Errors
Switch to a KDS

How to set up an Epson TM-T82II-i intelligent printer to print from any device using SplitAbility POS on a LAN.
The printer can be wireless or wired to the router (wireless requires the use of a wi-fi adapter).

The set up method described here uses a web browser to communicate with the TM-T82II-i (via the Epson TMNet WebConfig).

• Connect the TM-T82II-i printer to the network router with an ethernet cable then turn it on.
• The printer will claim a dynamic IP address and print the details.
• To print all settings - push and hold the reset button at the rear of the printer for 3 to 4 seconds (use a pen tip).
• Note: If you keep pressing the button for more than 10 seconds, factory default settings are restored.
• Using a PC connected to the network, browse to http://192.168.0.xyz/PrinterConfigurationPage/ (replace 192.168.0.??? with your IP address).
• Use the Login “epson”, password “epson”.
• Set the printer to use a static IP Address:
• [Configuration -› System Settings -› TCP/IP]
• [IP Address -› e.g. 192.168.0.250]
• [Subnet Mask -› as per default settings e.g. 255.255.255.0 ]
• [Default Gateway -› as per the default settings e.g. 192.168.0.1]

You can now add the printer IP address to SplitAbility POS and print from any device on the LAN.

To print graphics such as a logo on the customers receipt.

• Download and run: TM-T82II Utility.
• Alternatively search "TM-T82 Utility" download and run the utility.
• Connect the PC or Laptop to the printer via a USB connector.
• Use the "Storing Logos" function in order set and print graphics in relation to the paper cut.

See Also:
How to print using Wi-Fi Printers
